At present, the alignment of the turbine shaft line is in progress.
High-precision measuring instruments are used for pre-alignment of the shafting line. All five turbine rotors must be centred within 0.1 mm limit.
Alignment is done with the help of jacks located under the foundation frames of the bearing supports.
Now the specialists are finishing the work on the shafting line alignment. Then, the operation of transfer of the turbine unit to permanent backup plates will begin. They will be installed between the turbine foundation plates and poured with concrete. To perform further work, all five rotors will be removed from the linings of the turbine unit bearing assemblies.
After that, the alignment of the flow path of the turbine will begin.
Note:
Titan-2 Holding is the largest in the North-West group of companies, constructing the most important nuclear industry and power facilities. The company performs a full range of construction and installation works from engineering to commissioning.
Titan-2 Holding is the general contractor for the construction of the Leningrad NPP-2 power units. The Holding Companies perform all the civil, installation, and electrical works at a construction site. The works are carried out in the reactor, turbine, power supply, water supply, heat cogeneration buildings and other power unit structures.
The Holding is the main contractor for the construction of the Hanhikivi-1 NPP in Finland.
